Kobalt 5202572 - Product Specifications and Safety; Product Specifications

2
Product Specications ...................................................................................................... 2
Package Contents ............................................................................................................ 3
Know Your Tile Saw........................................................................................................... 6
Important Safety Information ............................................................................................. 8
Electrical Safety Information.............................................................................................. 11
Preparation........................................................................................................................ 14
Assembly Instructions ....................................................................................................... 15
Adjustment Instructions ..................................................................................................... 27
Operating Instructions ....................................................................................................... 30
Care And Maintenance ..................................................................................................... 35
Troubleshooting................................................................................................................. 37
Replacement Parts List ..................................................................................................... 38
Warranty ............................................................................................................................ 40
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
DESCRIPTION SPECIFICATIONS
Power Supply 120 V, 60 Hz
Motor 9 A
No Load Speed 5,700 RPM
Wheel 7 in. x 5/8 in. (arbor)
Maximum Depth of Cut 2-1/4 in.
Rip Capacity (tile size) 30 in.
Diagonal Capacity (tile size) 18 in.
Bevel Angles 0°, 22.5°, 45°
