3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Cutting head assembly 1
B Tile clamp 1
C Rip/Angle guide 1
D Water pump 1
E Cutting wheel 1
F Support legs 4
G Left support 1
H Right support 1
I Sliding table 1
C
B
A
MAX
MIN
D
E F
G
H
I
