8
ASSEMBLY INSTRUCTIONS
9. Tighten all hardware.
8. Secure the chest to the frame leg assemblies
by inserting bolts (M) through the posts and
into the chest and securing with a nut (L).
NOTE: On the same side as the pull handle,
only one bolt attachment will be used as the
handle uses the second position.
NOTE: Each corner of the chest has four
fasteners that will be installed when complete.
Bolt, M8x12
Nut, M8
x 10
x 10
Hardware Used
DD
8
M
L
To Next Page
