Kobalt 53278 User Manual

7
ASSEMBLY INSTRUCTIONS
6. Attach the handle (G) onto the chest (F)
on the same side as the locking swivel
casters (D). Insert two handle bolts (N)
from the exterior of the chest and secure
with with a nut (L).
7. Attach the side table (H) onto the chest (F)
opposite the pull handle (G). Insert four
bolts (M) from the exterior of the chest and
secure with four nuts (L).
AA
AA
6
7
Handle bolt, M8x16
Bolt, M8x12
Nut, M8
Nut, M8
x 2
x 4
x 2
x 4
Hardware Used
Hardware Used
N
G
F
F
G
D
L
M
L
H

Kobalt 53278 Specifications

General

Brand	Kobalt
Model	53278
Category	Tool Storage
Language	English
