13
WARNING
• The chute deector on the top of the discharge
chute controls the height of the snow stream.
Loosen the knobs to raise or lower the deector
to the desired height of snow you wish to throw.
Tighten the knobs to secure the deector.
• Do not advance the chute deflector too far forward
causing an opening to appear between the deflector
and discharge chute.
• Do not over-tighten the knobs on the chute deector.
Make sure that the chute deflector snaps and locks
completely onto the discharge chute. An opening
between the discharge chute and the chute deflector
may allow foreign objects to be picked up by the snow
thrower and thrown in the direction of the operator
causing serious boldly injury.
Always orient the discharge chute in the opposite
direction from where you, bystanders, surrounding
vehicles or windows are located.
The discharge chute can be adjusted 180 degrees
by pressing the change-over switch. Rotate the chute
control crank clockwise to move the discharge chute
to the left and counterclockwise to move the chute to
the right.
