Kobalt A081002 User Manual

20
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-888-3KOBALT (1-888-356-2258),
8 a.m. - 8 p.m., EST, Monday - Friday.
PART DESCRIPTION PART#
AA Handle knob/Deector knob 202028000132
BB Cable clip 8343-515101-0100130
CC Rubber washer 8202-660101-0000130
DD Chute crank rod 8206-517001-0000030
EE Carriage bolt 8SBJD08-30D
FF Square J-bolt 8087-660105-0000030
GG Chute deector 8101-660103-0000130
HH Impeller 199069000027
II Scraper bar 8181660905
JJ Belt 207130200005
HH
I I
JJ
AA BB CC
DD
GG
EE FF
Printed in China

Kobalt A081002 Specifications

General

Brand	Kobalt
Model	A081002
Category	Snow Blower
