PACKAGE CONTENTS
NOTICE: To simplify handling and to minimize any damage that may occur during shipping,
the router table comes partially assembled. Separate all the parts from the packaging materials
and check each part against the package contents list in order to ensure that all parts have
been included. Do this before discarding any of the packaging material.
Carefully inspect the items to ensure that no breakage or damage has occurred during shipping.
If any of the items in the parts list is missing, call customer service at 1-888-3KOBALT.
WARNING
• If any parts are missing, DO NOT attempt to assemble, install, or use the router table until
the missing parts have been found or replaced and the router table has been properly and
correctly assembled according to this owner’s manual.
Router table part list
PART
NO.
PARTS FOR ROUTER
TABLE
DESCRIPTION QUANTITY
aa
Router table surface assembly 1
ab
Table leg 2
ac
Switch box 1
ad
Pan-head screw with nut for installing
the switch box to the table
2
ae
M5x25 Hexagon socket-head screw,
and nut for installing the leg to the
table
4
af
M5x20 Hexagon socket-head screw,
pan washer, spring washer for
installing the leg to the table
4
ag
Flat-head screw for attaching the
router to the table
3
ah
Fence assembly 1
ai
Feather board 2
aj
M6x40 bolt, washer and knob for
attaching the feather boards to the
fence or the table
4
ak
Miter-gauge assembly 1
