Kobalt SC1802LW User Manual

21
To unlock the sliding table (Fig. 10)
From the right side of the sliding table (I), pull
the table lock lever (1) out and turn the lever
as shown.
To lock the sliding table (Fig. 10)
● Pull the table lock lever (1) out and slide the
table, and align the lock lever with either of the
two holes (2) on the table frame (J).
● Release the lever.
To lock/unlock the sliding T-fence extension
(Fig. 11)
● Loosen the two sliding T-fence lock knobs (EE)
to unlock the sliding T-fence extension (V). The
sliding T-fence extension can be pulled out.
● Tighten the two sliding T-fence lock knobs (EE)
to lock the sliding T-fence extension (V).
J
Unlock
Lock
11
2
I
1
Fold
V
Extend
V
EE
10
