Kobalt SM3017LW User Manual

14
4
INSTALLING THE HOLD-DOWN CLAMP
(FIG. 4)
NOTE: There are two mounting holes for the
hold-down clamp. These are located just behind the
fence on the left and right side of the base.
ŏ Loosen the lock knob (1) behind the fence.
Ɣ 3ODFHWKHKROGGRZQFODPSDVVHPEO\%LQWKH
desired mounting holes.
Ɣ 7LJKWHQWKHORFNNQRE
NOTE: Place the clamp on the opposite side of
the base when bevelling. Always make dry runs
XQSRZHUHGEHIRUH¿QLVKFXWVWRFKHFNWKHSDWKRI
the blade. Ensure the clamp does not interfere with
the action of the saw or guards.
Hold-down clamp mounting holes
B
1
