Kobalt SM3017LW User Manual

2
3URGXFW6SHFL¿FDWLRQV 2
Package Contents ........................................................................................................... 3
General Power Tool Safety Warnings ............................................................................... 4
Eletrical
Safety Information ............................................................................................... 9
Preparation ....................................................................................................................... 11
Assembly Instructions ....................................................................................................... 13
Adjustment Instructions ..................................................................................................... 15
Operating Instructions ....................................................................................................... 27
Crown Moulding Chart ...................................................................................................... 39
Care and Maintenance ..................................................................................................... 40
Troubleshooting ................................................................................................................ 42
Replacement Parts List ..................................................................................................... 43
Warranty ............................................................................................................................ 44
MOTOR CUTTING CAPACITY
Power Source 15A, 120V, 60 Hz Crosscut
Forward fence position:
3-1/2 in. x 14 in.
Fence back position:
2 in. x 16 in.
Arbor Shaft Size
5/8 in. with 1 in.
blade insert sleeve
Miter 45° Left & Left
Forward fence position:
3-1/2 in. x 9-7/8 in.
Fence back position:
2 in. x 11-1/2 in.
Speed (No load) 4200 RPM Bevel 45° Left 2 in. x 14 in.
Electric Brake Yes Bevel 45° Right 1-1/4 in. x 14 in.
Double Insulated Yes 45° Miter & 45° Bevel (left) 2 in. x 9-7/8 in.
BLADE 45° Miter & 45° Bevel (right) 1-1/4 in. x 9-7/8 in.
Diameter 12 in. Crown Moulding Nested 7-5/32 in.
Arbor 1 in. Base Moulding Against Fence 5-1/32 in.
Tooth Thickness 0.1 in. Miter Range 0
° -55 ° Left, 0 ° -60 ° Right
Bevel Range 0
° -48 ° Left & Right
MITER/BEVEL POSITIVE STOP ANGLES
Miter Detent Stops
0°, 15°, 22.5°, 31.6°, 45° left
0°, 15°, 22.5°, 31.6°, 45°, 60° right
Bevel Positive Stops 0°, 33.9°, 45°, 48° left & right
