5.1.2 Installation of Weighing Indicator
1: Fastening Nut for Lateral Rotation; 2: Fastening Nut for Vertical Rotation; 3:Locating Plate; 4: Printer
Weld the mounting bracket of the weighing indicator firmly
on the metal frame of the wheel loader driving cab. The
installation position should be convenient for operation.
Suggestion: Install the weighing indicator in the driving cab of
wheel loader and on the side the door which will not be
opened frequently.
1
2
3
4
