37
 Press key【Ent】to display the dialogue box ‘Save A0 or LR?’.
 If it’s the first time to do Zero Calibration or IdleAcc.Value A0 is not in the range
0.0030~0.0080dm/s
2
, please press key 【◄】/【►】 to select the button ‘Save LR’, then
press key【Ent】to save the new Zero Value and Run Length Ratio.
 If IdleAcc.Value A0 is in the range 0.0030~0.0080dm/s
2
, please press key【◄】/【►】 to
select the button ‘Save A0’, then press key【Ent】to save the new Zero Value and
IdleAcc.Value A0, and Run Length Ratio will not be changed.
 【Menu】: Exit without saving.
 Repeat the above steps for three times, if the variations of Zero Value and IdleAcc.Value A0 are
in the allowable range, Zero Calibration process will be completed.
 Press key【Pause】to enter Pause state with red sign ‘■’ displaying.
Alarm / Fault
Description
Sulution
【Zero Limit】
Zero Value is not in the allowed
range [0~130000].
Do ‘Oil Pressure Sensor Adjustment’ again.
【LR Limit】
Run Length Ratio is not in the
allowed range [0.001~9.999].
Do ‘Position Sensor Adjustment’ again.
【A0 Limit】
IdleAcc.Value A0 is not in the
allowed range [-0.0500~+0.0500
dm/s
2
].
Do ‘Position Sensor Adjustment’ again.
Zero Value Unstable
The variation of Zero Value has
exceeded 100.
Do ‘Oil Pressure Sensor Adjustment’ again.
Do ‘Wheel loader’s Idle Speed Adjustment’
again.
IdleAcc.Value A0
Unstable
Do ‘Position Sensor Adjustment’ again.
Do ‘Wheel loader’s Idle Speed Adjustment’
again.
