2 PRODUCT OVERVIEW
1
10
10
13
17
2
3
6
5
11
7
8
9
12
4
14
16
15
1 Pivot 10 Suction openings, front and back
2 Pedal for releasing the cloth holder
frame
11 Cleaning cloth on the cloth holder
frame in the device
3 Inspection flap 12 Tank installed
4 LED wave symbol 13 Tank release mechanism
5 Tank cap with dosage dispenser 14 Function key for applying water to the
cleaning cloth
6 Tank 15 MF600/601 cleaning cloths (Universal,
Universal Soft, Parquet, Dry)
7 Sealing lip frame (front) 16 Cloth holder frame
8 Cloth holder plate without the cloth
holder frame
17 Koboclean, various types
9 Sealing lip frame (back)
