KOCOM KHV-446S - Name of each Part; Main Body Installation

10_www.kocom.com Security Home Auto System_11
Lens 

Microphone
 Speaker
Power Lamp


Call Button
1. Blue: +12V (Camera Power)
2. Yellow: GND
3. Red: VOICE (Camera Voice Signal)
4.White: VIDEO (Camera Video Signal)
 Camera (KC-C50)
 Front Door Camera (KC-C50) Wiring Diagram
Name of Each Part
 Main Body
KHV-446ST and 456ST as standard
Functions vary according to the specifications of each
product.
 Extensions can be used only where direct dialing
system is installed.
