Specifications
MONITOR
(KVM-524RG)
CAMERA
(KC-D20)
Power source
Power consumption
Assurance temperature
Scanning frequency
Lens
Min. Illumination
Dimension
Illumination
Angle of picture
Color of KC-D20
DC12V 1V(power from Monitor)
Max: 2.5W
-10~50
Horizontal: 15.734KHz,15.625KHz
Vertical: 50Hz (CCIR)/60Hz (EIA)
F:2.0, f=3.0mm
0.1Lux (LED ON)
96(W)127(H)32(D)mm
Infra-red LED
Diagonal 120690(KC-D20)
Black or Silver
Power source
Power consumption
Ambient temperature
Braun tube
Communication system
Call signal sound
Output Impedance
Wiring
Max Wiring Distance
Dimension
AC 110V - 120V ~ (50Hz / 60Hz) or
AC 220V - 230V ~ (50Hz / 60Hz)
Max: 19W, Stand by : 4W
0~+50
4 inch Flat Tube (B/W)
Duplex handset conversation
Electric chime & beep sound
Picture : 75ohm, Voice : 600ohm
4 Wired in Polarity (VCC / GND/VOICE / PICTURE )
0.65 Single Cable/50m, 5C-2V Coaxial Cable/100m
210(W)222(H)53(D)mm
PLAY
AUTO
TIMES
REC
REC
Precautions for Operation
PLAY
AUTO
TIMES
REC
REC
B
E
N
Z
E
N
E
T
H
I
N
N
E
R
PLAY
AUTO
TIMES
REC
REC
P
L
A
Y
A
U
T
O
T
I
M
E
S
R
E
C
R
E
C
P
L
A
Y
A
U
T
O
T
I
M
E
S
R
E
C
R
E
C
PLAY
AUTO
TIMES
REC
REC
PLAY
A
UT
O
T
IMES
R
EC
R
EC
Keep away from humidifier and
stove. High temperature and
humidity can cause breakdown.
When cleaning, never use wet
hands, volatile benzene or paint
thinner.
Keep picture clear by cleaning
camera window frequently with
soft cloths.
As this device consists of
electronic precision
components, and high voltage
is generated internally, do not
attempt to disassemble.
Do not drop monitor or door
camera, and avoid strong
impact.
Keep away from devices
generating strong magnetic field
(TV, Speaker, etc.) (Picture can
be disturbed or blurred and
breakdown can result)
Installation Precautions
 Monitor and camera must be installed away from direct
light and counter light.
 Camera must be installed at a place free from rain.
 Standard height of monitor must be 1,450mm~1,500mm
from ground, centered around brawn tube.
 Camera should be installed on the wall in which cement
is completely dry.
 If installed during winter season at temperature below
-5, condensation might be generated inside monitor and
camera due to temperature difference between indoors
and outdoors. To prevent breakdown due to such
condensation, connection should be made in 2 hours or
more after installation.
 Do not install monitor and camera in locations subject to
direct heating as harmful gases may subsequently be
emitted in significant amounts.
 Stopping up pipe as above minimizes
temperature difference between indoors
and outdoors, and also eliminates
moisture and condensation on
door camera window.
Stop up P.V.C. pipe using
adiabatic substances, to
prevent air circulation
Component
Monitor Accessories
Screws for
fixing
4 x 30mm
 KDP-602G Connector Wire for
Extention
4 x 150mm (5264-04TYPE)
Wall hanger panel
Camera Accessories
Monitor & Camera
Main body
supporter
Screw for fixing camera
main body supporter
4 x 10mm
Screws for fixing camera
4 x 16mm
finishing rubber
Wall hanger panel is
packed in the Monitor
