Page | 8 Camera Overview
10
12
11
9
7
6
8
1. Camera Lens
(resolution HD(720p))
2. IR Sensor
3. Microphone
4. Pair Button
5. Micro-SD Card
Cover (Only up to 32GB
- Class 10 memory card)
6. Lens Frame
7. LED Power Indicator
8. Power ON/OFF Switch
13. Battery Door
14. Holes for wall
mount
14
13
9. Speaker
10. Charging Socket
11. Ball Joint Arm
12. Thermometer and
Humidity Sensor
CAMERA OVERVIEW
KODAK SMART BABY MONITOR C520
4
5
1
2
3
