Page | 10 KODAK Smart HomeCamera Overview
KODAK SMART BABY MONITOR C525/C525P
CAMERA OVERVIEW
3
4
1
2
6
7
5
1. IR Sensor
2. Camera Lens (with
resolution HD(720p))
3. Lens Frame with Tilt
function (up for 90°,
down for 15°)
4. Antenna
5. Pan function (330°)
6. LED Power Indicator
13. Micro-SD Card Cover
(Only up to 32GB - Class 10
memory card)
14. Thermometer and
Humidity
10
11
12
8
9
13
14
7. Charging Socket
8. Speaker
9. Microphone
10. Pair Button
11. Power ON/OFF Switch
12. Holes for Wall Mount
