INSTRUCTIONS OF HOW TO WALL MOUNT YOUR C520 CAMERA
9mm
1. First, put the screws on the wall. The diame-
ter of the screws should be at least 5mm and
maximum of 9mm. The distance between two
screws should be 69mm.
2. Place and match the wider holes on the base
of the camera with the screws.
3. Slide the base of the camera downwards so that the
screws lock towards the narrow side.
69mm
