Kodak EASYSHARE ZD710 User Manual

36 www.kodak.com/go/support
Doing more with your camera
Taking panoramic pictures
Use panorama to “stitch” up to 3 pictures into a panoramic scene.
1 Turn the Mode dial to Panorama .
2 Press to highlight Panorama Left-Right or Panorama Right-Left (depending
on the direction you want to pan), then press OK.
3 Take the first picture.
After a quickview, the LCD displays the liveview and an “overlay” from the first picture.
4 Compose the second picture. Make the overlay from the first picture cover the
same portion in the new picture. (You can press the Delete button to re-take a
picture.)
5 If you are taking only 2 pictures, press the OK button to stitch them together.
After you take 3 pictures, the pictures are automatically stitched together.
NOTE: For best results, use a tripod. Only the panoramic picture is saved; individual pictures are not. Picture
size is set to 3.1 MP. To use a self-timer delay, see page 11. Exposure, white balance, and focus are
set with the first picture. The flash is set to Off.
1
3
2
Take 2 or 3 pictures.
Get 1 panoramic picture.

Kodak EASYSHARE ZD710 Specifications

General

Megapixel	7.1 MP
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.5 \
Digital zoom	5 x
Optical zoom	10 x
Digital SLR	No
Minimum RAM	128 MB
Camera shutter speed	1/2–1/2000; 8-1/1000 s
Minimum storage drive space	200 MB
Minimum system requirements	USB
Compatible operating systems	WINDOWS XP OS + /INTERNET EXPLORER 6.0 +/MACINTOSH OS X 10.3 +/SAFARI 1.1 +
Focus	TTL
Focus adjustment	Auto
ISO sensitivity	80, 100, 200, 400, 800, 1600, auto
Internal memory	32 MB
Compatible memory cards	mmc, sd
Motion JPEG frame rate	30 fps
Video formats supported	QuickTime
Display diagonal	2 \
I/O ports	A/V NTSC/PAL
USB version	2.0
Product color	Black
Bundled software	KODAK EASYSHARE
Flash modes	auto, fill-in, Flash off, Red-eye reduction
White balance	auto, daylight, Fluorescent, Tungsten

Weight and Dimensions

Depth	72.6 mm
Width	97.8 mm
Height	77.5 mm
Weight	280 g
