Kodak OG-Plus3.24RM - Display Setting

21
96
Time setting – Hour
For hour setting, the range
is from 00 to 23.
97
Time setting– Day
For day setting, the range is
from 00 to 31.
98
Time setting– Month
For month setting, the
range is from 01 to 12.
99
Time setting – Year
For year setting, the range
is from 18to 99.
Display Setting
The LCD display information will be switched in turns by pressing “UP” or “DOWN” key. The selectable
information is switched as below order: input voltage, input frequency, PV voltage, MPPT charging current,
MPPT charging power, battery voltage, output voltage, output frequency, load percentage, load in VA,
load in Watt, DC discharging current, main CPU Version and second CPU Version.
Selectable information
LCD display
Input voltage/Output voltage
(Default Display Screen)
Input Voltage=230V, output voltage=230V
Input frequency
Input frequency=50Hz
PV voltage
PV voltage=60V
PV current
PV current=5.0A
PV power
PV power =500W
