Kogan LET40T3 - Page 38

Title Size Document Number Rev
Date: Sheet
of
HDTV
1.0
MSD209DG_BGA21x21_IC Demo board
A4
7 15Sunday, September 27, 2009
L804 0
R833 12K
C703 47nF
C820 NC
C818 NC
R824 75
C808 560pF
R706 10
C706 1nF
L806 0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
CN13 HDTV
R832 10K
1 2
Z806 ESD
Z800 ESD
R704 10
R825 75
R831 10K
1
1
2
2
3
3
4
4
5
5
6
6
7
7
CN11 HDTV_L/R
R703 470
C819 NC
C809 560pF
1 2
Z805 ESD
C705 47nF
R830 12K
C704 47nF
L805 0
Z801 ESD
1 2
Z804 ESD
R705 10
R826 75
HDTV-Rin 2
RGB2-SCART_G+ 2 RGB2-SCART_B+ 2 RGB2-SCART_SOG 2
HDTV-Lin 2
RGB2-SCART_R+ 2
HDTV-R HDTV-Rin
HDTV-LinHDTV-LHDTV-R
HDTV-L
HDTV_Pb
HDTV_Pr HDTV_Y
HDTV_Y HDTV_Pr HDTV_Pb
HDTV YPbPr INPUT
RGB2-SCART_SOG
HDTV_PBIN HDTV_YIN
Close to MStar IC
RGB2-RINP RGB2-BINP RGB2-SOGIN RGB2-GINP
RGB2-SCART_B+
RGB2-SCART_G+ RGB2-SCART_R+HDTV_PRIN
Service Manual
Model No.: LET40T3
37
