Kogan LET40T3 - Function Description: Display the Signal; Connector Definition

4-4-1. Function Description: Display the signal.
4-4-2. Connector denition:
Pin number Symbol Description
1 12V DC Power Supply
2 12V DC Power Supply
3 12V DC Power Supply
4 12V DC Power Supply
5 12V DC Power Supply
6 NC NC
7 GND Ground
8 GND Ground
9 GND Ground
10 Rx1[0]N 1
st
,5
th
LVDS Signal -
11 Rx1[0]P 1
st
,5
th
LVDS Signal +
12 Rx1[1]N 1
st
,5
th
LVDS Signal -
13 Rx1[1]P 1
st
,5
th
LVDS Signal +
14 Rx1[2]N 1
st
,5
th
LVDS Signal -
15 Rx1[2]P 1
st
,5
th
LVDS Signal +
16 GND Ground
17 Rx1CLK- 1
st
,5
th
LVDS Clock -
18 Rx1CLK+ 1
st
,5
th
LVDS Clock +
19 GND Ground
20 Rx1[3]N 1
st
,5
th
LVDS Signal -
21 Rx1[3]P 1
st
,5
th
LVDS Signal +
22 Rx1[4]N 1
st
,5
th
LVDS Signal -
23 Rx1[4]P 1
st
,5
th
LVDS Signal +
24 GND Ground
CN1 Connector
Service Manual
Model No.: LET40T3
16
