Pin number Symbol Description
25 Rx3[0]N 3
rd
,7
th
LVDS Signal -
26 Rx3[0]P 3
rd
,7
th
LVDS Signal +
27 Rx3[1]N 3
rd
,7
th
LVDS Signal -
28 Rx3[1]P 3
rd
,7
th
LVDS Signal +
29 Rx3[2]N 3
rd
,7
th
LVDS Signal -
30 Rx3[2]P 3
rd
,7
th
LVDS Signal +
31 GND Ground
32 Rx3CLK- 3
rd
,7
th
LVDS Clock -
33 Rx3CLK+ 3
rd
,7
th
LVDS Clock +
34 GND Ground
35 Rx3[3]N 3
rd
,7
th
LVDS Signal -
36 Rx3[3]P 3
rd
,7
th
LVDS Signal +
37 Rx3[4]N 3
rd
,7
th
LVDS Signal -
38 Rx3[4]P 3
rd
,7
th
LVDS Signal +
39 GND Ground
40 NC NC
41 NC NC
