Kogan LET40T3 - Page 19

Pin number Symbol Description
1 12V DC Power Supply
2 12V DC Power Supply
3 12V DC Power Supply
4 12V DC Power Supply
5 12V DC Power Supply
6 NC NC
7 GND Ground
8 GND Ground
9 GND Ground
10 Rx2[0]N 2
nd
,6
th
LVDS Signal -
11 Rx2[0]P 2
nd
,6
th
LVDS Signal +
12 Rx2[1]N 2
nd
,6
th
LVDS Signal -
13 Rx2[1]P 2
nd
,6
th
LVDS Signal +
14 Rx2[2]N 2
nd
,6
th
LVDS Signal -
15 Rx2[2]P 2
nd
,6
th
LVDS Signal +
16 GND Ground
17 Rx2CLK- 2
nd
,6
th
LVDS Clock -
18 Rx2CLK+ 2
nd
,6
th
LVDS Clock +
19 GND Ground
20 Rx2[3]N 2
nd
,6
th
LVDS Signal -
21 Rx2[3]P 2
nd
,6
th
LVDS Signal +
22 Rx2[4]N 2
nd
,6
th
LVDS Signal -
23 Rx2[4]P 2
nd
,6
th
LVDS Signal +
24 GND Ground
25 Rx4[0]N 4
th
,8
th
LVDS Signal -
26 Rx4[0]P 4
th
,8
th
LVDS Signal +
27 Rx4[1]N 4
th
,8
th
LVDS Signal -
CN2 Connector
Service Manual
Model No.: LET40T3
18
