Kogan LET40T3 - Page 20

Pin number Symbol Description
28 Rx4[1]P 4
th
,8
th
LVDS Signal +
29 Rx4[2]N 4
th
,8
th
LVDS Signal -
30 Rx4[2]P 4
th
,8
th
LVDS Signal +
31 GND Ground
32 Rx4CLK- 4
th
,8
th
LVDS Clock -
33 Rx4CLK+ 4
th
,8
th
LVDS Clock +
34 GND Ground
35 Rx4[3]N 4
th
,8
th
LVDS Signal -
36 Rx4[3]P 4
th
,8
th
LVDS Signal +
37 Rx4[4]N 4
th
,8
th
LVDS Signal -
38 Rx4[4]P 4
th
,8
th
LVDS Signal +
39 GND Ground
40 NC NC
41 NC NC
42 NC NC
43 NC NC
44 NC NC
45 LVDS_SEL
HIGH (3.3V) Normal LVDS Format
LOW (GND) JEIDA LVDS Format
46 NC NC
47 NC NC
48 NC NC
49 NC NC
50 NC NC
51 NC NC
Service Manual
Model No.: LET40T3
19
