60 TP-7044 6/23
I/O Menu
I/O Menu (Continued)
Active Events Menu
• Resistive Input
Analog Input 0:1
Analog Input 0:2
Analog Input 0:3
Analog Input 0:4
Analog Input 0:5
Analog Input 0:6
o DESCRIPTION: (function by
default unless modified via
SiteTech)
o MEASUREMENT: ###.#Ohms
o EVENT: *
o INPUT ENABLED: ON/OFF*
o SENSOR TYPE: *
o LOW PROTECTIVE INHIBIT:
##s*
o LOW WARNING: ON/OFF*
o LOW WARNING LIMIT: *
o LOW WARNING DELAY: ##s*
o LOW SHUTDOWN: ON/OFF*
o LOW SHUTDOWN LIMIT: *
o LOW SHUTDOWN DELAY:
##s*
o HIGH PROTECTIVE INHIBIT:
##s*
o HIGH WARNING: ON/OFF*
o HIGH WARNING LIMIT: *
o HIGH WARNING DELAY: ##s*
o HIGH SHUTDOWN: ON/OFF*
o HIGH SHUTDOWN LIMIT: *
o HIGH SHUTDOWN DELAY:
##s*
• Digital Input
Digital Input 0:1
Digital Input 0:2
Digital Input 0:3
Digital Input 0:4
Digital Input 0:5
Digital Input 0:6
o DESCRIPTION: (function by default
unless modified via SiteTech)
o STATUS: ACTIVE/INACTIVE
o FUNCTION: *
o EVENT: *
o LOGIC: ACTIVE ON/ACTIVE OFF *
o ENABLED: ON/OFF*
o INHIBIT TIME: ##s*
o DELAY TIME: ##s*
• Digital Output
Digital Output 0:1
Digital Output 0:2
Digital Output 0:3
Digital Output 0:4
Digital Output 1:1
(Note:
Only displayed if the 15-Relay
Dry Contact Kit is installed.)
o DESCRIPTION: (function by default
unless modified via SiteTech)
o STATUS: ACTIVE/INACTIVE
o FUNCTION: *
o EVENT: *
o LOGIC: ACTIVE ON/ACTIVE OFF*
Rotate the dial to view Active Events:
Warnings
Shutdowns
Statuses
Notices
See the System Fault Warning Lamp with
Digital Displays, System Fault Shutdown
Lamp With Digital Displays, and Status
and Notice Digital Displays sections for
descriptions.
Press the OFF button to return to the
main menu.
* User-Defined (changeable) Menu Displays. Use SiteTech™ software to change other settings including User-Defined Menu Displays.
