TP-7092 11/22 21
Figure 6 Battery Heater (typical)
1.8.3 Breather Tube Heater and Oil Heater Kit
The breather tube heater and oil heater kit is recommended for improved cold starting in locations where the ambient temperature
drops below 0°C (32°F).
Note:
The heaters require a continuous source of AC power. See Figure 7 and Figure 8 for the power supply voltage required.
Note:
The breather tube heater and oil heater must be used together.
Verify that AC power is connected to the generator set as described in the generator set Installation Manual. The circuit must be
backed up by the generator set to provide power at all times. Refer to TT-1709 for instructions to install the heaters and connect
120VAC power.
See Figure 9 and Figure 10 for illustrations of the 120VAC breather tube heater and oil heater.
Heater Part Number
GM110893, GM110894
Voltage
120 VAC
Thermostat ON
4°C (40°F)
Thermostat OFF
13°C (55°F)
Figure 7 Breather Tube Heater Specifications
Heater Part Number
GM110895, GM110896
Voltage
120 VAC
Thermostat ON
4°C (40°F)
Thermostat OFF
13°C (55°F)
Figure 8 Oil Heater Specifications
Figure 9 Breather Tube Heater
Power cord
Battery heater wrap
Retaining strap or cable ties
(included)
Heating element
Label
Thermostat
120 VAC female connector
(connect to oil heater)
120 VAC plug
