Kohler 17.5CCFOZ

TP-5592 7/96 Wiring Diagrams 5-7
7 6 8 5
11 10 12 9
15 14 16 13
L2
L3
To Generator
Set
To Shore
Power
To Load
4-Wire, three phase
Generator Sets
L0
3 2 4 1
L1
L2
L3
L0
L1
L2 L3 L0L1
Kraus Naimer/American Solenoid
I-940
Figure 5-6. Marine Manual (Ship-to-Shore) Transfer Switch
