TP-6953 7/1968 Section 2 Operation
SiteTecht Parameter
Write
Access
Units
Decision-Maker
r
3500
User Interface
Notes
Genset Low Voltage Shutdown Limit Always % Undervoltage: ##% Percentage of System
Voltage that the
generator voltage must
drop below for an under
voltage condition to be
indicated
Genset High Voltage Shutdown Limit Always % Overvoltage: ##% Percentage of System
Voltage that the
generator voltage must
exceed for an over
voltage condition to be
indicated
Genset Short Term Low Frequency Shutdown Delay None s
Genset Long Term Low Frequency Shutdown Delay None s
Genset High Frequency Shutdown Delay None s
Genset Low Frequency Shutdown Limit Always % Underfrequency: ##% Percentage of System
Frequency that the
generator frequency must
drop below for an under
frequency condition to be
indicated
Genset High F requency Shutdown Limit Always % Overfrequency: ##% Percentage of System
Frequency that the
generator frequency must
exceed for an over
frequency condition to be
indicated
Programmable Digital Input
Digital Input Board Number None I/O Board N umber: X Indicates board number
this IO point is located on
Digital Input Io Number None Indicates the point
number, of this IO type
on this board, for this
configuration
Digital Input Status None The current value of the
input (scaled to the units
of the function ID)
Digital Input Enabled Always Enabled: On/Off Indicates whether this
input is enabled
Digital Input Logic Always Thetypeofswitchthatis
connected to the input,
where “normal” refers to
the non-activated state
Digital Input Function Always Function: Indicates the functionality
of this IO point
Digital Input Event Always Event: The parameter ID
defining the function for
this input
Digital Input Delay Always s Delay Time: ##s Thetimethattheinput
must be active before a
status change is
indicated
Digital Input Inhibit Delay Always s Inhibit Time: ##s Thetimethattheinput
must be active before a
status change is
indicated
Digital Input Description Alway s Description: A user-defined
description of this IO
point
Programmable Digital Output
Digital Output Board Number None I/O Board Number: X Indicates board number
this IO point is located on
Digital Output Io Number
Not supported for these models.
Digital Output Status
Digital Output Enabled
Digital Output Logic
Digital Output Function
Digital Output Event
Digital Output Description
