TP-6953 7/19 71Section 2 Operation
SiteTecht Parameter
Write
Access
Units
Decision-Maker
r
3500
User Interface
Notes
Circuit Breaker Current Fault Delay Always s CB Current Fault Delay: ##.#s 10 = 1.0 Sec
Volts Hertz Okay Time Delay Always s Volts-Hz OK Delay: ##.#s
Sync Mode In Auto Always Sync Mode in Auto:
Invalid/Off/Passive/C heck/
Active/Dead Field
Sync Mode In Run Always Sync Mode in Run:
Invalid/Off/Passive/C heck/
Active/Dead Field
Circuit Breaker Phase Angle Fault Limit Always
_ CB Phase Fault Limit: ##.#
_
Circuit Breaker Phase Angle Fault Delay Always s CB Phase Fault Delay: ##.#s
Dead Bus Level Always % Dead Bus Level: ##.#%
Pickup Acceptable Voltage Window Always % Voltage OK Pickup: ##.#%
Dropout Acceptable Voltage Window Always % Voltage OK Dropout: ##.#%
Pickup Acceptable Frequency Window Always Hz Frequency OK Pickup: ##.#Hz
Dropout Acceptable Frequency Window Always Hz Frequency OK Dropout: ##.#Hz
Stand Alone Operation Always Stand Alone Mode: O n/Off
PGen Baud Rate Always b/s PGEN Baud Rate: OFF/9600
b/s/19200 b/s/38400 b/s/
57600 b/s/115200 b/s
PGen Node Id None PGEN Node ID: ##
PGen Nodes Connected None PGEN Nodes Online: ##
PGen Nodes Disconnected None PGEN Nodes Offline: ##
Fail To Open Delay Always s Fail to Open Delay: ##s
Fail To Close Delay Always s Fail to Close Delay: ##s
Voltage Match Proportional Gain Always Voltage Match P Gain: ##.##
Voltage Match Integral Gain Always Voltage Match I Gain: ##.##
Voltage Match Derivative Gain Always Voltage Match D Gain: ##.##
Frequency Match Proportional Gain Always Freq Match P Gain: ##.##
Frequency Match Integral Gain Always Freq Match I Gain: ##.##
Frequency Match Derivative Gain Always Freq Match D Gain: ##.##
Phase Match Proportional Gain Always Phase Match P Gain: ##.##
Phase Match Integral Gain Always Phase Match I Gain: ##.##
Phase Match Derivative Gain Always Phase Match D Gain: ##.##
Generator Paralleling Breaker None
External Bias Inputs Enabled Always
Synchronization Metering
Sync Time Remaining None s Sync Time Remaining: ####s (Secx10)
Sync Dwell Time Remaining None s Dwell Time Remaining: ##.#s (Secx10)
Sync Status Generator V Hz OK None Volts-Hz OK: True/False Bit 0: Gen_VHz_OK
Sync Status Voltage Matched None Voltage Matched: True/False Bit 1: Synch_V_Matched
Sync Status Frequency Matched None Frequency Matched: True/False Bit 2:
Synch_Freq_Matched
Sync Status Phase Matched None Phase Matched: True/False Bit 3:
Synch_Phase_Matched
Sync Check Matched Ok None In Sync: True/False
Real Power Load Sharing
Real Power Baseload Setpoint Always % 250 = 25.0%
Real Power Disconnect Level Always % kW Disconnect Level: ##.#% 100 = 10.0% of rated kW
Real Power Ramp Rate Always %/s kW Ramp Rate: ##.#%/s 50 = 5.0% of rated
kW/Sec
Real Power Droop Slope Always %@FL 20 = 2.0 % of rated
speed @ 100% rated kW
Speed Bias None Speed Bias: ###.## 5000 = 50.00 Note:
speed bias is equal to
% speed x 10 (5000 - >
50.00 - > +5% Voltage)
Load Enable Always Load Enabled: On/Off
Base Load Mode Always
System Load Control Always System Load Control: On/Off
System Sync Control Always System Sync Control: On/Off
Trims Enabled Always Trims Enabled: On/Off
Real Power Sharing Proportional Gain Always kW Sharing P Gain: ##.##
Real Power Sharing Integral Gain Always kW Sharing I Gain: ##.##
Real Power Sharing Derivative Gain Always kW Sharing D Gain: ##.##
Torque Sharing Proportional Gain Alway s
