TP-6953 7/1972 Section 2 Operation
SiteTecht Parameter
Write
Access
Units
Decision-Maker
r
3500
User Interface
Notes
Torque Sharing Integral Gain Always
Torque Sharing Derivative Gain Always
Frequency Trim Proportional Gain Always Freq Trim P Gain: ##.##
Frequency Trim Integral Gain Always Freq Trim I Gain: ##.##
Frequency Trim Derivative Gain Always Freq Trim D Gain: ##.##
Real Power Baseload Proportional Gain Always
Real Power Baseload Integral Gain Always
Real Power Baseload Derivative Gain Always
System Real Load Control Proportional Gain Always
System Real Load Control Integral Gain Always
System Real Load Control Derivative Gain Always
Reactive Power Load Sharing
Reactive Power Baseload Setpoint Always % 600 = 60.0% Rated kVAR
Power Factor Setting Always 80 = 0.80 PF lagging,
- 90 = 0.90 PF leading
Reactive Droop Slope Always %@FL 40 = 4.0% rated Volts @
100% rated KVAR
Voltage Bias None Voltage Bias: ###.## 5000 = 50.00 Note
voltage bias is equal to %
voltage x 10 (5000 - >
50.00 - > +5% Voltage)
Var Control Mode Always
Reactive Power Sharing Proportional Gain Always kVAR Sharing P Gain: ##.##
Reactive Power Sharing Integral Gain Always kVAR Sharing I Gain: ##.##
Reactive Power Sharing Derivative Gain Always kVAR Sharing D Gain: ##.##
Voltage Trim Proportional Gain Always Volt Trim P Gain: ##.##
Voltage Trim Integral Gain Always Volt Trim I Gain: ##.##
Voltage Trim Derivative Gain Always Volt Trim D Gain: ##.##
Reactive Power Baseload Proportional Gain Always
Reactive Power Baseload Integral Gain Always
Reactive Power Baseload Derivative Gain Always
Power Factor Baseload Proportional Gain Always
Power Factor Baseload Integral Gain Always
Power Factor Baseload Derivative Gain Always
System Reactive Power Control Proportional Gain Always
System Reactive Power Control Integral Gain Always
System Reactive Power Control Derivative Gain Always
System Power Factor Control Proportional Gain Always
System Power Factor Control Integral Gain Always
System Power Factor Control Derivative Gain Always
Generator Management
Gen Management Control Mode Always Gen Management Mode:
Invalid/Manual Fixed/
Run Time/Fuel Level
Gen Management Enabled Always Gen Management: On/Off
Gen Management Order Always Gen Management Order: # Only editable if in Manual
Mode
Gen Management Start Percent Always % Start Capacity: ###.#%
Gen Management Stop Percent Always % Stop Capacity: ###.#%
Gen Management Start Delay Always s Start Delay: ####s
Gen Management Stop Delay Always s Stop Delay: ####s
Gen Management Start Accumulator None Start Accumulator: #####
Gen Management Stop Accumulator None Stop Accumulator: #####
Gen Management Start KW None kW Start kW: #####kW
Gen Management Stop KW None kW Stop kW: #####kW
Gen Management Stable Delay Always s Stable Delay: ####s
Gen Management Run Time Threshold Always h Run Time Threshold: ###.#hrs Only if in Run Time
Management
Gen Management Fuel Difference Threshold Always % Fuel Level Threshold: ##.#% Only if in Fuel Level
Management
Gen Management Min Gens Online Always Minimum Gens Online: ##
Gen Management Min Load Shed Priority Always Min Loads Added: ##
Gen Management Stopped By Gen Mgmt None Stopped by Gen Mgmt:
True/False
