Kohler 20RESC Installation

TP-6803 6/1530 Section 1 Installation
tp6809
PIM
RXT ATS
Generator Set
Notes:
D See Figure 1-17 for terminal block location on generator
set. Check the decal on the generator set for terminal
block connections.
D See Section 1.10.2, Cable Specifications.
D See Figure 1-24 for communication connection detail (A
and B, PWR and COM). Connect the cable shield to
ground at the generator set.
D Use splices or wire nuts to collect multiple leads for
connection to the generator set terminal block. See
Figure 1-27.
Terminal
Block
Load
Shed
Kit
Figure 1-28 Accessory Module Connections (two cable runs with one and two modules shown)

Kohler 20RESC Specifications

General

Rated Output (Gasoline)	20 kW
Rated Output (LPG)	18 kW
Voltage	120/240 V
Frequency	60 Hz
Fuel Type	Gasoline, LPG, Natural Gas
Starting System	Electric
Warranty	5 years limited
Dimensions	48.5 in L x 29 in H
