TT-1596 8/22 3
Related Literature
A single-phase paralleling system is made up of the
APM module covered by this instruction sheet plus two
generator sets and a Model RXT transfer switch. A load
control module (LCM), load shed kit, or combined
interface/load management board on the RXT is
required if one generator set cannot support the
maximum total load. An optional PIM and OnCuer Plus
monitoring system m ay also be used with the power
system. Refer to the documentation provided with the
other system components for installation instructions.
Related literature is listed in Figure 4.
Document Description Part Number
SiteTecht Software Operation Manual
TP-6701
OnCuer Plus Operation Manual
TP-7006
OnCuer Plus Technical Manual
TP-7007
Installation Manual, 14/20RESA, 20RESC TP-6803
Operation Manual, 14/20RESA, 20RESC TP-6804
Installation Manual, 20RESB, 20RESD TP-6925
Operation Manual, 20RESB, 20RESD TP-6926
Installation Manual, 14RCA and 20RCA TP-7091
Operation Manual, 14RCA and 20RCA TP-7092
Operation/Installation Manual, Model RXT
Transfer Switch
TP-6807 or
TP-7193
Installation Instructions, Load Control Module
(LCM)
TT-1574
Installation Instructions, Programmable
Interface Module (PIM)
TT-1584
Installation Instructions, Load Shed Kit TT-1609
Figure 4 Related Literature
Safety Precautions
Observe the following safety pr ecautions while installing
the kit.
Accidental starting.
Can cause severe injury or death.
Disconnect the battery cables before
working on the generator set.
Remove the negative (- ) lead first
when disconnecting the battery.
Reconnect the negative (- ) lead last
when reconnecting the battery.
WARNING
Disabling the generator set. Accidental starting can
cause severe injury or death. Before working on the
generator set or equipment connected to the set, disable the
generator set as follows: (1) Press the generator set off/reset
button to shut down the generator set. (2) Disconnect the
power to the battery charger, if equipped. (3) Remove the
battery cables, negative (- ) lead first. Reconnect the negative
(- ) lead last when reconnecting the battery. Follow these
precautions to prevent the starting of the generator set by the
remote start/stop switch.
Hazardous voltage.
Will cause severe injury or death.
Disconnect all power sources before
opening the enclosure.
DANGER
Grounding electrical equipment. Hazardous voltage will
cause severe injury or death. Electrocution is possible
whenever electricity is present. Ensure you comply with all
applicable codes and standards. Electrically ground the
generator set, transfer switch, and related equipment and
electrical circuits. Turn off the main circuit breakers of all
power sources before servicing the equipment. Never contact
electrical leads or appliances when standing in water or on wet
ground because these conditions increase the risk of
electrocution.
Short circuits. Hazardous voltage/current will cause
severe injury or death. Short circuits can cause bodily injury
and/or equipment damage. Do not contact electrical
connections with tools or jewelry while making adjustments or
repairs. Remove all jewelry before servicing the equipment.
Making line or auxiliary connections. Hazardous voltage
will cause severe injury or death. To prevent electrical
shock deenergize the normal power source before making any
line or auxiliary connections.
Electrical backfeed to the utility. Hazardous backfeed
voltage can cause severe injury or death. Install a transfer
switch in standby power installations to prevent the connection
of standby and other sources of power. Electrical backfeed
into a utility electrical system can cause severe injury or death
to utility personnel working on power lines.
