Kohler 23EKOZD Installation Instructions

7
TT-1651 4/17a
Bracket Location
on Service Side
Bracket Location
on Non Service Side
Bracket Location
on Engine End
Bracket Location
on Alternator End
1
GM93548-A
GM89517-C
1. Panel mounting bracket (GM77222 qty. 7), c arriage bolt
(X-6224-20 qty. 7), and hex. nut (X-6210-7 qty. 7)
2. Panel mounting bracket (GM82181), carriage bolt (X-6224-20),
and hex nut (X-6210-7)
11
2
Figure 15 Mounting Bracket Location in Top Rails
