TP-6137 5/0344 Section 8 Controller Troubleshooting
1. Control panel
2. Connector (to STD control panel connector)
3. 0.63 amp fuse
4. J3 connector (to control panel)
5. P5 connector (to remote panel harness)
6. P6 connector (to remote start/stop switch connector)
7. J6 remote start/stop switch connector
8. Remote start/stop switch
1
3
4
2
5
6
7
8
8
Figure 8-3 Control Panel
