TP-6344 4/09 31Section 4 Troubleshooting
4.5 Controller Troubleshooting
Figure 4-3 contains troubleshooting information for the
Advanced Digital Control.
Problem Possible Cause Corrective Action
Controller LED
displayisoff.
No power to the controller:
Controller powers down if the generator set
has not run for 48 hours or longer.
Controller display will automatically activate when a
remote start command is received or the generator
set master switch is moved to the RUN position.
Controller fuse (F3) is blown. Replace the fuse. See Figure 4-1. If the fuse blows
again, contact an authorized Kohler distributor/
dealer.
Low or no battery voltage. Check connections.
Check generator set battery. See Figure 4-2.
Generator set master switch is in the
OFF/RESET position.
Move generator set master switch to the AUTO or
RUN position.
Figure 4-3 ADC 2100 Troubleshooting Chart
