TP-6907 5/16 13Section 1 Specifications
Section 1 Specifications
1.1 Introduction
The specification sheets for each generator set provide
specific generator and engine information. Refer to the
generator set specification sheet for ratings and other
data not supplied in this manual. Consult the generator
set installation manual, engine operation manual, and
engine service manual for additional specifications.
Consult the generator set nameplate for specific
generator set r atings.
1.2 Controller Specifications
The generator sets covered in this manual are equipped
with the RDC2 controller. For a specific description of
the controller, see the generator set operation manual.
Environmental Specifications RDC2 Controller
Operating temperature
-- 3 0 _ to 70_C
Storage temperature
-- 4 0 _ to 85_C
Humidity 5--95% condensing
Voltage Requirements
Controller operation 12 VDC
Built-in battery charger 120 VAC
1.3 Engine Service
Generator sets covered in this manual are equipped
with a 2.2L (134.25 cu. in.) 4-cycle, four-cylinder,
liquid-cooled Kohler engine.
For engine service information and specifications not
covered in this manual, see the engine service manuals.
See the List of Related Materials in the Introduction
section.
Generator Set Model Engine
24RCL KG2204 Naturally Aspirated
30RCL KG2204T Turbocharged
38RCLB KG2204T Turbocharged
1.4 Engine Specifications
Selected engine specifications are shown on the
generator set specification sheets. For additional
engine specifications, refer to the engine Service
Manuals. See the List of Related Materials in the
Introduction section.
1.5 Alternator Specifications
Selected alternator specifications are shown on the
generator set specification sheets and also shown in the
table below. See the alternator service manual for more
information.
Alternator Specifications
Manufacturer Kohler
Exciter type Brushless, Wound-Field
Voltage regulator Solid State, Volts/Hz
Insulation: NEMA MG1
Material Class H
Temperature rise
130_C, Standby
Bearing: quantity, type 1, Sealed
Coupling Flexible Disc
Amortisseur windings NA
Voltage regulation, no-load to
full-load
1.0% Maximum
Unbalanced load capability 100% of Rated Standby Current
One-step load acceptance 100% of Rating
1.6 Torque Specifications
For alternator assembly torque specifications, refer to
the alternator service manual.
For engine assembly torque specifications, refer to the
engine service manual.
See the List of Related Materials in the Introduction
section for document part numbers.
