TP-6907 5/1640 Section 3 Controller
SiteTech Grou p Notes [
Default
Setting
Adjustment
Range *
UnitsParameter
Source 2 Metering Source 2 Frequency Hz Read Only N/A RXT
ATS Connection
Configuration
ATS Source Read Only N/A RXT
Source 1 System
Configuration
Source 1 System Voltage V 110.0 -- 600.0 Genset
System
Voltage
RXT
Source 1 System
Configuration
Source 1 System Frequency Hz 48.0 -- 62.0 Genset
System
Frequency
RXT
Source 1 System
Configuration
Source 1 Voltage Debounce
Delay
s 1--99 0.5 RXT
Source 1 System
Configuration
Source 1 Low Voltage Pickup % 85 -- 100 90 RXT
Source 1 System
Configuration
Source 1 Low Voltage Dropout % 75 -- 98 90 RXT
Source 1 Calibration Source 1 Calibration Factor
Voltage L1-L2
Read Only 1 RXT
Source 1 Calibration Source 1 Calibration Factor
Voltage L2-L3
Read Only 1 RXT
Source 1 Calibration Source 1 Calibration Factor
Voltage L3-L1
Read Only 1 RXT
Source 2 System
Configuration
Source 2 System Voltage V 110.0 -- 600.0 240.0 RXT
Source 2 System
Configuration
Source 2 System Frequency Hz 48.0 -- 62.0 60.0 RXT
Source 2 System
Configuration
Source 2 Voltage Debounce
Delay
s 0.1 -- 9.9 0.5 RXT
Source 2 System
Configuration
Source 2 Low Voltage Pickup % 85 -- 100 90 RXT
Source 2 System
Configuration
Source 2 Low Voltage Dropout % 75 -- 98 90 RXT
Source 2 Calibration Source 2 Calibration Factor
Voltage L1-L2
Read Only 1 RXT
Source 2 Calibration Source 2 Calibration Factor
Voltage L2-L3
Read Only 1 RXT
Source 2 Calibration Source 2 Calibration Factor
Voltage L3-L1
Read Only 1 RXT
ATS Exercise Exercise Interval Weekly or
Every Other Week
Weekly RXT
ATS Exercise Exercise Run Duration min 10 -- 30 20 RXT
ATS Exercise Exercise Mode Pulldown
See List
Unloaded
Cycle (2)
RXT
ATS Exercise Exercise Warning Enabled True or False True RXT
ATS Delays ATS Transfer From Preferred
Delay
s 1--10 3 RXT
ATS Delays ATS Transfer From Standby
Delay
s 1 -- 600 120 RXT
ATS Delays ATS Source 2 Engine Start
Delay
s 1--10 3 RXT
Modbus Is Modbus Master 0--1 0
* Read Only = Not adjustable
w Load management device (LCM, load shed kit, or RXT with combined interface/ load management board).
[ Notes indicate applicability to genset or accessories. N/A = Not applicable to the models covered in this manual.
] See TT-1584 for more information about digital inputs and outputs.
Grayed rows are visible in SiteTech but do not apply to all models.
