Kohler 4EOZ User Manual

TP-6137 5/0334 Section 6 Cooling System
Waterline
4
5
13
6
7
8
9
10
11
12
15
14
3
2
1
TP-5586-3
1. Silencer vertical lift 1.2 m (4 ft.) max.
2. Exhaust outlet distance from the waterline. Use a siphon break if
the exhaust mixer outlet is located less than 23 cm (9 in.) above
the waterline.
3. Siphon break distance above waterline 30.5 cm (1 ft.) min.
4. Siphon break
5. Exhaust outlet
6. Seawater strainer
7. Seacock
8. Intake strainer
9. Gear-driven seawater pump
10. Exhaust hose pitch 1.3 cm per 30.5 cm (0.5 in. per ft.) min.
11. Water lock (optional)
12. Silencer distance from exhaust outlet 3 m (10 ft.) max.
13. Silencer (customer supplied)
14. Exhaust hose pitch 1.3 cm per 30.5 cm (0.5 in. per ft.) min.
15. Exhaust outlet distance above the waterline 10 cm (4 in.) min.
Figure 6-6 Siphon Break, Plastic “U” Type
Note: Do not locate the siphon break directly above the
generator set.
