TP-6255 7/0630 Section 4 Fuel System
10--32EOZD and 9--27EFOZD Models:
1. Place the generator set on/off switch in the OFF
position.
2. Disconnect the generator set engine starting
battery, negative (-- ) lead first.
3. Close the fuel supply valve.
4. Loosen the fuel filter by turning it counterclockwise.
Remove the fuel filter and use rags to clean up
spilled fuel oil. Dispose of the fuel filter and rags in
an approved manner.
5. Clean the c ontact surface of the fuel oil filter
adapter.
6. Lightly lubricate the gasket surface of the new fuel
filter with fresh fuel oil. Thread the filter on the
adapter until the gasket makes contact;
hand-tighten the filter an additional one-half turn.
Wash hands after any contact with fuel oil.
7. Open the fuel supply valve.
8. Reconnect the generator set engine starting
battery, negative (-- ) lead last.
9. Bleed the system. See Section 4.2.1, Bleeding the
Fuel System.
1
TP-606111
1. Fuel filter adapter
2. Fuel filter
3. Removal (counterclockwise)
4. Installation (clockwise)
<
<
<
<
2
3
4
Figure 4-3 Spin-On Fuel Oil Filter
