Kohler 8-32EOZD

TP-6255 7/06 51Section 7 Controller
Parameter Setting Definition Connect
Unit’s system voltage and
f
[
Single phase, 2 Wire, 60 Hz, 100 VAC 1Ph, 2W
y
g
frequency [
U
u
0
0
Single phase, 3 Wire, 60 Hz, 100 VAC 1Ph, 3W
U
u00
Single phase, 2 Wire, 60 Hz, 120 VAC 1Ph, 2W
Single phase, 3 Wire, 60 Hz, 120 VAC 1Ph, 3W
U
u
0
1
Single phase, 3 Wire, 60 Hz, 120/240 VAC 1Ph, 3W
U
u01
Single phase, 3 Wire, 60 Hz, 120/240 VAC Dogleg
Uu02 Single phase, 2 Wire, 50 Hz, 230 VAC 1Ph, 2W
Uu03 Three phase, 4 Wire, 50 Hz, 230/400 VAC Wye
Uu04 Three phase, 4 Wire, 60 Hz, 277/480 VAC Wye
Single phase, 2 Wire, 50 Hz, 100 VAC 1Ph, 2W
U
u
0
5
Single phase, 3 Wire, 50 Hz, 100 VAC 1Ph, 3W
U
u05
Single phase, 2 Wire, 50 Hz, 110 VAC 1Ph, 2W
Single phase, 3 Wire, 50 Hz, 110 VAC 1Ph, 3W
Uu06 Single phase, 3 Wire, 50 Hz, 115/230 VAC 1Ph, 3W
U
u
0
7
Single phase, 3 Wire, 50 Hz, 110/220 VAC 1Ph, 3W
U
u07
Single phase, 3 Wire, 50 Hz, 110/220 VAC Dogleg
Uu08 Single phase, 3 Wire, 60 Hz, 100/200 VAC 1Ph, 3W
Uu09 Single phase, 3 Wire, 50 Hz, 100/200 VAC 1Ph, 3W
U
u
1
0
Three phase, 4 Wire, 60 Hz, 120/240 VAC Delta
U
u10
Three phase, 4 Wire, 60 Hz, 139/240 VAC Wye
Uu11 Three phase, 4 Wire, 60 Hz, 120/208 VAC Wye
Uu12 Single phase, 2 Wire, 50 Hz, 220 VAC 1Ph, 2W
Uu13 Single phase, 2 Wire, 50 Hz, 240 VAC 1Ph, 2W
Uu14 Three phase, 4 Wire, 50 Hz, 115/230 VAC Delta
Uu15 Three phase, 4 Wire, 50 Hz, 110/220 VAC Delta
Uu16 Three phase, 4 Wire, 60 Hz, 127/220 VAC Wye
Uu17 Three phase, 4 Wire, 50 Hz, 110/190 VAC Wye
Uu18 Three phase, 4 Wire, 50 Hz, 120/208 VAC Wye
Uu19 Three phase, 4 Wire, 60 Hz, 220/380 VAC Wye
U
u
2
0
Three phase, 4 Wire, 60 Hz, 240/416 VAC Wye
U
u20
Three phase, 4 Wire, 60 Hz, 230/400 VAC Wye
Uu21 Three phase, 4 Wire, 50 Hz, 220/380 VAC Wye
Uu22 Three phase, 4 Wire, 50 Hz, 240/416 VAC Wye
Unit configuration Uc00 Marine generator set
Engine type
Ec01 8--9EOZD/6.5-- 7EFOZD
g
y
p
Ec02 10--20EOZD/9-- 17.5EFOZD and 24EOZD/20EFOZD
Ec07 28--32EOZD/23-- 27EFOZD (Units without the preheater option)
Ec09 23EOZD/20EFOZD (Units with the preheater option)
Engine data input types
(
N
t
i
i
k
)
Ed00 All digital inputs
g
p
y
p
(No magnetic pick-up)
Ed01 Digital: Low coolant level and low oil pressure. Analog: Low coolant temperature
Ed02 Digital: Low coolant level and low coolant temperature. Analog: Low oil pressure
Ed03 * Digital: Low coolant level. Analog: Low coolant temperature and low oil pressure
Ed08 Digital: Low coolant temperature and low oil pressure. Analog: Low coolant level
Ed09 Digital: Low oil pressure. Analog: Low coolant level and low coolant temperature
Ed10 Digital: Low coolant temperature. Analog: Low coolant level and low oil pressure
Ed11 All analog inputs
Battery Voltage
Bt12 Battery voltage 12 VDC
y
g
Bt24 Battery voltage 24 VDC
Communications
Cn00 No CAN communications
Cn01 SAE J1939 (Used for ADC remote digital gauge)
Cn02 Future CANbus
* Factory default setting for 8--32EOZD and 6.5--27EFOZD marine models.
[ Check the generator set spec sheet for voltage configurations applicable to each model. Use voltage/frequency parameters Uu07--Uu22 only
with ADC application program version 1.20 or higher.
Figure 7-6 Controller Parameters
