TP-6255 7/06 53Section 7 Controller
or
To set the engine data input type.
To enter battery voltage selection mode.
or
To toggle between 12 and 24 VDC.
To enter communications selection mode.
or
To set the communications parameter mode.
To enter SAVE mode. Go to Figure 7-9.
E d 0 x
Pressing the up arrow key at the Adnc display (See Figure 7-7) puts you into
the Advanced Configuration Mode.
Press:
B t 1 2
C n 0 0
S A V E
B t 2 4
12-volt models
24-volt models
Note: Shaded boxes show which number in the controller display changes when the up or down arrow
keyispressed. “x” denotes any number from 0 to 9.
Figure 7-8 Advanced Configuration Mode (engine data input types, battery voltage, and engine
communications)
To save changes.
To discard changes without saving.
or
Note: Be sure to save your settings before exiting the configuration mode. The controller reverts to the
last saved settings when the master switch is moved to the OFF/RESET position.
* x in the runtime hours display above denotes any number from 0 to 9.
S A V E
Y E S
Now move the master switch to OFF/RESET.
n o
There are 3 options when the display says SAVE:
Press:
x x xx
or
To return to the first parameter, system voltage/frequency Uu,
to check or change settings before saving. See Figure 7-7.
U u 0 x
“Yes”or “no” flashes when the up or down arrow is pressed and then
the controller exits the configuration mode. The display returns to
the runtime hours.
Figure 7-9 Save Mode (after configuring generator set parameters)
