Kohler CH18 User Manual

7724 690 06 Rev. P KohlerEngines.com
Electrical System
Wiring Diagram-3 Amp Unregulated Battery Charging System/70 Watt Lighting
K
C
B
L
F
H
A
J
G
O
S
N
D
M
T
I
E
P
S
R
Q
A
R
S
B
A
Optional Oil
Sentry
™
Switch
(Shutdown)
B 12 V. Battery C
Optional Oil
Sentry
™
Switch
(Indicator Light)
D Light E
Ground-To-Kill
Lead (White)
F Ground G
Optional
Ammeter
H Optional Fuse I Key Switch J Red
K Blue L Solenoid M Lights N Starter O Yellow
P Diode Q
3 Amp/70 Watt
Flywheel Stator
R Black S Spark Plug(s) T Ignition Modules

Kohler CH18 Specifications

General

Compression Ratio	8.5:1
Fuel Type	Gasoline
Cooling System	Air-cooled
Ignition System	Electronic
Starter Type	Electric
Power	18 hp (13.4 kW)
Oil Capacity	1.4 L (1.5 qt)
Lubrication	Full Pressure
