Specications
1162 690 01 Rev. J KohlerEngines.com
Engine Dimensions with Low-Prole Air Cleaner - PTO Side
A 427.8 mm (18.84 in.) B 107.9 mm (4.25 in.) C
85.5 mm (3.37 in.)
Lifting Point
D
Lifting Point
10 X 12 mm
(0.39 X 0.47 in.) Slot
E Oil Level Dipstick F M8 X 1.25 mm Studs G 45° H 35°
I 30° J
60.0 mm (2.37 in.)
Exhaust Port #1
K
481.2 mm (16.47 in.)
Lifting Point
L 340.8 mm (13.42 in.)
M
181.9 mm (7.16 in.)
Starter Stud
N Mounting Hole "A" O
68.6 mm (2.70 in.)
Starter Stud
P 106.0 mm (4.17 in.)
Q
177.8 mm (7.01 in.)
Pilot
R
M8 X 1.25 mm-6H in.
25 mm (0.98 in.)
Deep on a Ø 254 mm
(10.0 in.) B.C.
S
4 X 7/16-14 UNC-2B in.
21 mm (0.83 in.) Deep
on a Ø 142.88 mm
(5.625 in.) B.C.
T
4 X 3/8-16 UNC-2B in.
17 mm (0.67 in.)
Deep on a Ø 196.88
mm (7.750 in.) B.C.
U 142.9 mm (5.63 in.) V 254.0 mm (10 in.) W 196.9 mm (7.75 in.) X
2 X 35.0 mm (1.38 in.)
Gasket
Y
60.0 mm (2.36 in. )
Exhaust Port #2
A
D
C
B
E
F
G
G
J
Y
X
K
L
M
N
O
P
G
G
Q
R
S
T
U
V
W
G
G
I
I
H H
