10.15
Section 10
Internal Components
10
Figure 10-25. Inspect for Binding.
5. Check to see that the closure plate/oil passages to
the reduction assembly are open and not
restricted. See Figures 10-26 and 10-27.
Figure 10-26. CS4, CS6 Oil Passage.
Figure 10-27. CS8.5-12 Oil Passage.
