Kohler Command PRO CS

Section 11
Reassembly
11.10
Figure 11-39. CS8.5-12. 2:1 Reduction Assembly Components.
Figure 11-38. CS4, CS6. 2:1 Reduction Assembly Components.
No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
Bolt
Chain Case Cover
Gasket
Dowel Pin
Oil Seal
Bearing
Washer
Bolt/Washer
Shaft 2
Idle Sprocket
Chain
Washer
Straight Key
C Oil seal installation depth
2 mm
(0.08 in.)
30 N·m (265 in. lb.)
65 N·m (48 ft. lb.)
No. Description
1
2
3
4
5
6
7
8
9
Chain Case Cover
Gasket
Dowel Pins
Oil Seal
Bearing
Bolt/Washer
Idle Gear
Straight Key
Shaft
8
9
5
6
7
3
4
3
2
1
C Oil seal installation depth
2 mm
(0.08 in.)
D Tightening sequence
A 22 N·m (195 in. lb.)
B 10 N·m (88 in. lb.)
1
4
2
5
3
13
12
9
10
8
7
6
3
2
4
5
1
11
