Kohler Command PRO CS User Manual

8.8
Section 8
Electrical System and Components
Figure 8-4.
Figure 8-5.
Wiring Color Codes
B
L
R
Y
W
Br
G
Gy
B/W
R/W
W/L
G/R
G/Y
L/W
L/R
G/B
Oil Sentry™ Gauge Lead
Black
Blue
Red
Yellow
White
Brown
Green
Gray
Black w/White Stripe
Red w/White Stripe
White w/Blue Stripe
Green w/Red Stripe
Green w/Yellow Stripe
Blue w/White Stripe
Blue w/Red Stripe
Green w/Black Stripe
Black w/Gray Shielding
Ignition Module
Spark
Plug
Ground
Ground
Stop
Switch
Wire Lead B
Ignition Module
Spark
Plug
Ground
Ground
Ground
Ground
Stop
Switch
Wire Lead
B
B
B
B
BW
BW BW
Y
Y
L
Oil Warning
Unit
Oil Sentry™ Gauge
Oil Sentry™ Light
B
BW
R or BR
R or BR
B
Electronic Ignition System,
Recoil Start.
Electronic Ignition System,
with Oil Sentry™ System.
Recoil Start.
