8.8
Section 8
Disassembly
Short Screw Hole
Coil
Lift Strap
Figure 8-30. Note Location of Short Screws.
6. Remove the remaining hex ange screws
securing the blower housing. Remove the blower
housing. See Figure 8-31.
Silver
Screw
2. Remove the silver plated recti er-regulator
ground strap screw fastened to the crankcase.
The recti er-regulator does not have to be
detached from the blower housing.
3. Disconnect the three fuse connectors a ached to
the outer ba e on the starter side. Allowing them
to hang is ne.
NOTE: Some engines may have two fuses mounted
to a bracket above the ECU and a third in-line
fuse near the recti er-regulator.
4. Remove the three (each side) hex ange screws
securing the outer ba es. Note the location of
any li ing strap and the position of the two short
screws (one each side on bo om) for reassembly.
See Figure 8-30. The coil and any hoses may
remain a ached to the ba e a er being
unplugged or disconnected.
5. Remove the outer ba es. See Figure 8-30.
Figure 8-27. Plastic Grass Screen.
Remove Four Screws
Remove Four Screws
Figure 8-28. Plastic Grass Screen.
Remove Outer Baf es and Blower
Housing
1. Disconnect the plug from the recti er-regulator.
See Figure 8-29.
Figure 8-29. Disconnect Plug from Recti er-
Regulator.
