Kohler Command PRO EFI

Specifi cations
16 24 690 01 Rev. SKohlerEngines.com
TORQUE SPECIFICATIONS
3,5
ECH630-ECH680 ECH730-ECH749 CH26 CH735 CH745
Muffl er
Retaining Nut 27.8 N·m (246 in. lb.) 24.4 N·m (216 in. lb.)
Oxygen Sensor smaller 14 mm
(9/16 in.) wrench size
18 N·m (159 in. lb.)
Oxygen Sensor larger 22 mm (7/8 in.)
wrench size
50.1 N·m (37 ft . lb.)
Oil Cooler
Oil Cooler/Adapter Nipple 28.5 N·m (21 ft . lb.) 27 N·m (20 ft. lb.)
Fastener
Into Blower Housing
Between Oil Cooler Hoses
2.8 N·m (25 in. lb.)
2.3 N·m (20 in. lb.)
Speed Control Bracket (if equipped)
Fastener Assembled to Cylinder Heads 10.7 N·m (95 in. lb.) into new holes
7.3 N·m (65 in. lb.) into used holes
Fastener Assembled to Blower Housing 2.8 N·m (25 in. lb.) into new holes
2.3 N·m (20 in. lb.) into used holes
Fastener Torque 10.7 N·m (95 in. lb.) into new holes
7.3 N·m (65 in. lb.) into used holes
Starter Assembly
Thru Bolt
Nippondenso (Solenoid Shift)
Delco-Remy (Solenoid Shift)
5.6-9.0 N·m (49-79 in. lb.)
4.5-7.5 N·m (40-84 in. lb.)
5.6-9.0 N·m (49-79 in. lb.)
Mounting Screw 16.0 N·m (142 in. lb.) 15.3 N·m (135 in. lb.)
Brush Holder Mounting Screw
Delco-Remy Starter
2.5-3.3 N·m (22-29 in. lb.)
2.5-3.3 N·m (22-29 in. lb.)
Starter Solenoid
Mounting Hardware
Nippondenso Starter
Delco-Remy Starter
4.0-6.0 N·m (35-53 in. lb.)
6.0-9.0 N·m (53-79 in. lb.)
4.0-6.0 N·m (35-53 in. lb.)
Nut, Positive (+) Brush Lead
Nippondenso Starter
Delco-Remy Starter
8.0-11.0 N·m (71-97 in. lb.)
8.0-12.0 N·m (71-106 in. lb.)
8.0-11.0 N·m (71-97 in. lb.)
Stator
Mounting Screw 9.3 N·m (82 in. lb.)
Valve Cover
Fastener
Gasket Style Cover
Black O-Ring Style Cover
w/Shoulder Screws
w/Flange Screws and Spacers
Yellow or Brown O-Ring Style
Cover w/Integral Metal Spacers
9.0 N·m (80 in. lb.)
3.4 N·m (30 in. lb.)
5.6 N·m (50 in. lb.)
9.9 N·m (88 in. lb.)
9.0 N·m (80 in. lb.)
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
