1. Préparer le site
Plancher fini
Sous-plancher
2-1/4 po (57 mm) Min
3-1/16 po (78 mm) Max
Support en bois
Mur fini
7-7/8 po (200 mm) Min
Plancher fini
2-3/4 po (70 mm) Min
Baignoire
Ligne centrale de la base
Solive de plancher
Kohler Co. 19
1443292-2-B
F
R
